MODEL: SN-B6
VISCOUS AND LIQUID FILLING MACHINE
Power
200V 2kw 3 phase
Capacity
1200 to 1500 bottles per hr
Machine Size
L4000 x W1500 x H2000mm
Capability
Automatic filling from 100 to 1000ml with no overflow sensor
Air Compressor Requirement
3kw (7bars) not included
with cap dispenser, cap tightening device, easy adjustable bottle size, applicable for any bottle type, changeable capping head.
MODEL: SN-B3ES
VISCOUS FILLING MACHINE
200-220v 1.5kw, 3 phase
800 to 1000 bottles/hr
L2800 x W800 x H1800mm
adjustable from 15 to 60 grams
approx 5hp at 8 bars. 3hp
With rotary feeding table, 2 stage viscous filler, & liquid filler, cap rail, cap tightening device.
Pneumatic & PLC driven control.
MODEL: SN-B2V
GEAR TYPE VISCOUS FILLING MACHINE
220V 200w, single or 3 phase
20 bottles/minute @200grams
L600 x W800 x H1850mm
100g~4000g fill volume
1hp (7bars) not included
Floor type with stainless frame, adjustable foot mounting
PLC Controlled electric control panel
Easy cleanable type, adjustable and programmable fill volume
MODEL: SN-B1V
PLC controlled electric control panel
MODEL: SN-P1
SEMI AUTOMATIC PISTON VISCOUS FILLING MACHINE
10~12 strokes/minute
L700 x W700 x H1700mm
100ml~1000ml fill volume
3hp (7bars) not included
Simple, compact, easily changeable bottle size, the all-in-1 machine
MODEL: SN-MY2
PISTON FILLER VOLUME 500g WITH CAP TIGHTENER
800-1,200pcs/hr, 200~500grams
Manual 1kg-5kg
Easily Changeable bottle holder
