VISCOUS FILLING MACHINE
MODEL: SN-B6
VISCOUS AND LIQUID FILLING MACHINE
Power
200V 2kw 3 phase
Capacity
1200 to 1500 bottles per hr
Machine Size
L4000 x W1500 x H2000mm
Capability
Automatic filling from 100 to 1000ml with no overflow sensor
Air Compressor Requirement
3kw (7bars) not included
with cap dispenser, cap tightening device, easy adjustable bottle size, applicable for any bottle type, changeable capping head.
MODEL: SN-B3ES
VISCOUS FILLING MACHINE
Power
200-220v 1.5kw, 3 phase
Capacity
800 to 1000 bottles/hr
Machine Size
L2800 x W800 x H1800mm
Capability
adjustable from 15 to 60 grams
Air Compressor Requirement
approx 5hp at 8 bars. 3hp
With rotary feeding table, 2 stage viscous filler, & liquid filler, cap rail, cap tightening device.
Pneumatic & PLC driven control.
MODEL: SN-B2V
GEAR TYPE VISCOUS FILLING MACHINE
Power
220V 200w, single or 3 phase
Capacity
20 bottles/minute @200grams
Machine Size
L600 x W800 x H1850mm
Capability
100g~4000g fill volume
Air Compressor Requirement
1hp (7bars) not included
Floor type with stainless frame, adjustable foot mounting
PLC Controlled electric control panel
Easy cleanable type, adjustable and programmable fill volume
MODEL: SN-B1V
GEAR TYPE VISCOUS FILLING MACHINE
Power
220V 200w, single or 3 phase
Capacity
20 bottles/minute @200grams
Machine Size
L600 x W800 x H1850mm
Capability
100g~4000g fill volume
Air Compressor Requirement
1hp (7bars) not included
Floor type with stainless frame, adjustable foot mounting
PLC controlled electric control panel
Easy cleanable type, adjustable and programmable fill volume
MODEL: SN-P1
SEMI AUTOMATIC PISTON VISCOUS FILLING MACHINE
Power
220V 200w, single or 3 phase
Capacity
10~12 strokes/minute
Machine Size
L700 x W700 x H1700mm
Capability
100ml~1000ml fill volume
Air Compressor Requirement
3hp (7bars) not included
Simple, compact, easily changeable bottle size, the all-in-1 machine
MODEL: SN-MY2
PISTON FILLER VOLUME 500g WITH CAP TIGHTENER
Power
Capacity
800-1,200pcs/hr, 200~500grams
Machine Size
Capability
Manual 1kg-5kg
Air Compressor Requirement
Easily Changeable bottle holder
